Mo86c Batterie Versendoket 2/A.R.266. image

Information

Mo86c Batterie

Details

Roscoff is the furthest port on the north west coast of France with sailing links now to Ireland and Plymouth. The Batterie we are looking at here is just south of St-Pol de Leon.


St-Pol de Leon by Sarazin de Belmont mid 1800's.

Mo86c Batterie Versendoket 2/A.R.266.

Google

Information

Mo86c Batterie

Details

Batterie 2/A.R.266.
4 x R669's casemates Max, Moritz, Ulli & Ural. .
5 x ammunition bunkers.
4 x 7.62cm FK39 (r) guns.
1 x 2cm Flak 30.
This Batterie was to cover Carentec & the island of Callot. The Batterie never fired a shot in anger and all its troops & equipment were withdrawn into Brest when the Americans closed in.


St-Pol de Leon.


St-Pol de Leon cathedral.




Mo86c Batterie Versendoket 2/A.R.266. image

Geoportail

Information

Mo86c Batterie

Details

The bunkers are dispersed amongst the farm buildings.


7.62cm FK39 (r) guns.


R669's casemate for a field gun with a 60degree arc of firing. Two small ammunition rooms and a rear entrance.
.


R669 under construction.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

The first. Turm 1 R669 Casemate 'Max'


Plan of the Batterie.


Plan of the Batterie.




Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 2 H669 Casemate 'Moritz'.
This embrasure is now filled in with a window.


This one seems to have a small flanking wall on its front left side.


Image Caption

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 2 H669 Casemate Rear 'Moritz'.
The rear doors I believe were to be armoured, they may never have been fitted as this Batterie was being built in early 1944.


there were small ammunition bunkers and the red ones may have been for fuze's?. There were crew bunkers & a bunker for power, usually a small generator.


Bunker generator.


Image Caption

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 2 'Moritz' and Turm 3 'Ulli'.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 3 'Ulli' Rear Entrance.
The gun would pass through the rear entrance and would be set up to fire through the front embrasure. Fire orders would be sent from the fire control post at Roscoff Mo94.


R627 an artillery observation bunker with a canopy at Roscoff Mo94.


Command cables coming from Roscoff.


Observation.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 3 'Ulli' Gun Room. The gun room has plenty of space.


Air extraction in the roof to remove the smoke after the gun has fired.


200mm air vents on the outside back wall of the bunker.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 3 'Ulli' Ammunition Room.
The ammunition niche with a painted arrow.
Inset : the black mark on the wall is for chalking the ammunition scales in the niche.


Ammunition Niche.


7.62 ammunition.


Inlet & outlet for the smoke to be removed from the gun room. There would have been a large electric fan placed here.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 3 'Ulli' Gun Embrasure.


Ventilation through an R669's.


Ventilation fan.


200mm rear vent.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 4 'Ural'


Image Caption


7.62 Batterie firing in the open.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

Turm 4 'Ural'.
Rear entrance of Ural, we did not go right inside as there is a heating plant running.


There was one 2cm Flak 30 protecting the Batterie.


2 cm Flak 30.

Mo86c Batterie Versendoket 2/A.R.266.image

21 November 2009

Information



Details

Turm 3 'Ulli' the bunkers code name "schwenkber" means "Schwenkbereich" - Swivelling range. The angle the gun can fire in an H669 casemate is 60degrees.


The angle the gun can fire in an H669 casemate is 60degrees.


These were horse drawn Batterie and the guns would have been in field positions since they arrived in Brittany. Then in 1944 they were placed inside casemates. The horses would have been kept and used as personal transport and the delivery of stores and ammunition.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

Mo86c Batterie

Details

"Ulli". Thank you Georg for the translation.

Mo86c Batterie Versendoket 2/A.R.266. image

21 November 2009

Information

St-Pol de Leon

Details

Some additional details will go here


St-Pol de Leon.


The bay they were there to protect.

Mo86c Batterie Versendoket 2/A.R.266.

21 November 2009

Information

Three Batterie Positions.

Details

The Germans kept 3 horse-drawn batteries permanently in the region of Saint-Pol de Leon to defend the Bay of Morlaix. They were mobile field artillery pieces of 10.5cm to 1.50cm along with heavy anti-aircraft guns & searchlights. It was not until June 1943 - February 1944 that the construction of 12 casemates type 669 starts and many underground bunkers used to shelter personnel, ammunition & power. The staff consisted of one hundred men, including many Russian assigned to teams.
