RAF Needs Oar Point ALG
Information
RAF Needs Oar Point ALG
Details
An Advanced Landing Ground, there were many airfields built in Britain during WW2 and most had a complete infrastructure and runways. With ALG's these were built as an airfield that can be erected quickly and also remove very quickly and placed back into food production.
With D-Day looming, more space and runways were needed in the south of England. They came up with ALG's. Temporary runways of Sommerfeld Tracking (a wire mesh strengthened with steel rods and pinned to the turf with steel spikes like tent pegs). Pierced Steel planking was also used for aircraft hard standings and marshalling areas. Very few huts were built and most lived in tents or the odd requisitioned house/farm. Aircraft servicing was done in one of the four Blister hangars.
Fuel was stored in underground tanks and ammunition/bombs were stored in open compounds. The reason for a lot of this lac of infrastructure was to come into its own when D-Day arrived and ALG's were built all across the French countryside as the Allies advanced into Germany. Some airmen never slept under a solid roof for over six months.
Sommerfeld tracking.
Pierced Steel Planking. PSP.
ALG Blister hangars.
Petrol POOL articulated tanker, delivering to the airfields.
.303 SAA machine gun belts.
1000lb bombs.
RAF Needs Oar Point ALG
Information
RAF Needs Oar Point ALG
Details
RAF Needs Oar Point ALG
Air Ministry site plan 578/44 original 06:04:1943
Information
RAF Needs Oar Point ALG
Plan
Details
Plan of the airfield. Air Ministry site plan 578/44.
Grey - Sommerfeld Tracking runways.
White - perimeter tracks and aircraft dispersals
Green - air-raid trenches, larger are trees and woodland.
Tents and farm house requestioned.
2 pilots per tent.
Large tents for the mess and supplies.
48 hour pass to visit London, Plymouth, or Tangmere.
The weather was bad a lot of the time which was especially tough for the grounds crew who had to work outside in it.
Spent time in the beach house near Needs Oar.
Lots of prep time and lectures; kept busy.
Laying Sommerfeld Tracking.
Digging air-raid trenches.
RAF Needs Oar Point ALG
27 March 2012
Information
RAF Needs Oar Point ALG
Panel
Details
Needs Oar Point Airfield was constructed by a Flight of No.5004 Airfield Construction Squadron RAF on farm land at Park Shore in 1943 by levelling the land, filling in or diverting ditches, removing some hedges and trees and laying
Sommerfeld Tracking. Four Blister Hangars were added later. Some cottages were
used when the Squadrons moved in, but most personnel lived in tented sites near
the airstrip. All maintenance was done from mobile workshops in a large fleet
of lorries. A battery of heavy AA guns of the Royal Artillery was sighted of school
cottages and light gun positions near the coast were manned by the RAF Regiment.
No.146 Wing, 84 Group of the Second Tactical Airforce RAF arrived to use the airfield
on the 10th & 11th April 1944. This small but strategically sited airfield became the
base for over 100 Hawker Typhoon fighter-bombers of 193, 197, 257 & 266 Squadrons.
They immediately began flying missions over France in preparations for the D-Day
landings. Attacks were made on road and rail targets and radar sites. On D-Day and
for the next four weeks these Squadrons flew sorties in support of the troops then
advancing in Normandy, including attacks on German Headquarters.
At the beginning of July 1944 the Squadrons left Needs Oar Point Airfield for Hurn
for two weeks before moving to bases that had been built in Normandy.
in 1945 the land was returned to farming and the tracking and hangars removed.
This commemorative panel is placed at the point where the Nort-South Runway
crossed the road. It is placed here a a tribute to all concerned with the Liberation.
193 Sqn RAF.
197 Sqn RAF.
257 Sqn RAF.
RAF Needs Oar Point ALG
Google
Information
RAF Needs Oar Point ALG
N/S runway
Details
On the right is the board.
Plan.
Rocket attacks in Normandy.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Runway
Details
The view looking almost due north..
Plan.
Typhoon..
D-Day Typhoons.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Air photo
Details
Air photo showing the AA site, fuel instillation and two Blister hangars.
Plan.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Air photo
Details
Another probably earlier photo showing the AA site and the two Blister hangars.
AA gun..
Tents.
Gun cleaning.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Blister hangars
Details
Blister hangars at dispersal.
Plan.
A Spitfire being serviced in a Blister hangar.
Frame of a Blister hangar.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Typhoon
Details
Typhoon taking off past one of the farm houses.
Plan.
RAF Needs Oar Point ALG
1944 266 Sqn
Information
RAF Needs Oar Point ALG
266 Sqn
Details
Members of 266 Sqn, May 1944. Formed 27 September 1918 at Mudros, Aegean Disbanded Rattlesden 30 June 1964.
No.266 'Rhodesia' Squadron was a fighter squadron that operated Spitfires during 1940 and 1941 before converting to the Hawker Typhoon at the start of 1942, using that aircraft with Second Tactical Air Force during the liberation of Western Europe. (Wiki)
No.266 'Rhodesia' Squadron.
266 Sqn Typhoon.
Attacking a train in France.
RAF Needs Oar Point ALG
03 February 2003
Information
RAF Needs Oar Point ALG
Details
The layout of runways looking north from the beach. The runways were grass covered in Sommerfeld tracking and since the war, and the fields ploughed up. So there are very few remains to see.
Plan.
RAF Needs Oar Point ALG
03 February 2003
Information
RAF Needs Oar Point ALG
Details
The runway running N/S across the road, which would have been closed at the time.
Plan.
RAF Needs Oar Point ALG
27 March 2012
Information
RAF Needs Oar Point ALG
Details
The runway would have run L to R.
Plan.
RAF Needs Oar Point ALG
27 March 2012
Information
RAF Needs Oar Point ALG
Remains
Details
Remains in the farm of concrete used as hard stand and maybe road ways.
Plan.
RAF Needs Oar Point ALG
27 March 2012
Information
RAF Needs Oar Point ALG
Remains
Details
The odd bricks that were used in some buildings possibly the fuel pump house.
RAF Lymington brick fuel pump house.
RAF Needs Oar Point ALG
27 March 2012
Information
RAF Needs Oar Point ALG
Runway
Details
E/W runway.
Plan.
RAF Needs Oar Point ALG
1943
Information
RAF Needs Oar Point ALG
Fuel instillation
Details
The Air Ministry plan of the extending of the fuel instillation to allow more vehicles to use it. It shows, that the amount of aircraft movements were greater than anticipated by the authorities when the airfield was designed. Tankers probably would arrive from the petrol refineries at Fawley, near Southampton Water, in Petrol POOL articulated road tankers and stored in large underground petrol tanks. Then pumped up into smaller RAF lorry fuel bowser´s to be delivered to the planes.
Plan.
Petrol POOL articulated tanker, delivering to the airfields.
Bedford fuel bowser.
Bowser trailer tanker.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Fuel instillation
Details
The fuel instillation with its roadway and possibly a brick pump house. RAF Lymington fuel instillation does have a brick pump house.
RAF Lymington fuel pump house.
Pumps in a pump house.
Plan.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Sleeping
Details
Everybody was under canvas, meaning tented accommodation. Tents were ridge or bell type. Here it looks like ridge tents and made of very heavy strong canvas and wooden poles & tent pegs. It would have been cold at night and in wet weather, very muddy.
Officers tent.
Large Mess & dining tents.
Home for two.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Aircraft dispersal
Details
Short stubby dispersals were laid out with Sommerfeld Tracking to park aircraft, where they could be stored. Other areas were PSP planking, these were to re arm and re fuel and last PSP planking at the ends of runways for marshalling aircraft prior to take off. Remember there were over 100 fighters stationed here, so it would get very crowded at times.
Servicing a Typhoon on a dispersal point.
Bombing up.
Re fuelling.
RAF Needs Oar Point ALG
Flight Sergeant Fraser Petherbridge No.100sqd.
Information
RAF Needs Oar Point ALG
Take off
Details
100 Squadron Typhoon taking off. (not stationed here).
RAF Needs Oar Point ALG
00-00-00
Information
RAF Needs Oar Point ALG
Airfield defence
Details
The anti-aircraft defence of RAF Needs Oar Point. Eight Vickers 3.7inch AA guns and in the centre the predictor/range finders. There were two types of mountings, one mobile as here and the other fixed as in proper anti-aircraft positions. When the aircraft left for France, these guns may have followed or were sent to the Dover area for anti Diver Operation against the V1 attacks.
ATS range finding in the centre of a batterie.
The Vickers QF 3.7-inch AA was Britain's primary heavy anti-aircraft gun during World War II. It was roughly the equivalent of the German 88 mm Flak. Production began in 1937. It remained in use after the war until AA guns were replaced by guided missiles beginning in 1957.
Vickers 3.7inch guns firing.
40mm Bofors AA guns were situated by the waters edge.
40mm Bofors AA gun.
There were probably several Lewis AA guns around.
RAF Needs Oar Point ALG
1944
Information
RAF Needs Oar Point ALG
Airfield defence
Details
One of the mobile Vickers 3.7inch AA guns in its position. A solid raft was made for the gun to sit on using sometimes railway tracks and sleepers and even concreting them in.
With its Matador tractor unit.
Mobile and on its wheels.
Set up and ready.
RAF Needs Oar Point ALG
03 February 2003
Information
RAF Needs Oar Point ALG
Needs Oar Point
Details
France
Great Britain
